In high-precision research and advanced hardware applications, uniform fluid distribution can make or break system performance. Today, we are excited to spotlight one of our recently custom-fabricated components: a High-Precision Microfluidic Branching Manifold Chip.
Designed with an intricate multi-tier bifurcation network, this transparent fluidic chip exemplifies the synthesis of micro-scale fluid dynamics and precision machining.
Key Features & Highlights
- Multi-Tier Fractal Branching Network:
Featuring a 4-level symmetric bifurcation design ($1 \rightarrow 2 \rightarrow 4 \rightarrow 8 \rightarrow 16$), the manifold splits a single incoming fluid stream into 16 parallel micro-channels with identical hydraulic path lengths, ensuring 100% uniform flow rate and pressure distribution.
- High Optical Transparency:
Crafted from premium optical-grade PMMA / Quartz, allowing full optical clarity for direct fluid visualization, particle tracking, or optical sensing over the central target area.
- Integrated Central Working Window:
The open central square aperture is engineered to seamlessly integrate with external targets—such as high-heat-flux electronic chips, optical windows, micro-sensor arrays, or biological reaction zones.
- Leak-Proof Micro-Bonding:
Utilizing advanced precision bonding technology, the cover layer is seamlessly sealed without channel deformation, collapse, or adhesive blockage in the narrow passages.
- Standardized Fluidic Interfaces:
Equipped with precision-machined Luer-lock compatible ports at both inlet and outlet, allowing easy, low-dead-volume connection to standard microfluidic pumps, tubing, and fittings.
Ideal Applications
This custom microfluidic manifold is engineered for demanding applications, including:
- Microchannel Heat Sinks: Liquid cooling plates for high-power lasers, CPVs, and microelectronics where localized hotspots must be eliminated.
- Biomedical & Lab-on-a-Chip Systems: Even distribution of reagents, nutrients, or cellular suspensions across parallel reaction zones.
- Chemical Micro-Reactors: Uniform multi-channel fluid delivery for high-throughput chemical synthesis and analysis.
Customization Capabilities
Every research project and industrial device has unique geometry and fluidic requirements. We offer full custom prototyping and manufacturing services tailored to your exact specifications:
- Substrate Materials: PMMA, PC, COC/COP, PDMS, Glass, or Quartz.
- Channel Dimensions: Custom channel widths and depths
- Connector Types: Luer lock, threaded ports, barb fittings, or direct capillary tubing interfaces.
- Surface Treatments: Hydrophilic/hydrophobic surface modifications or anti-fouling coatings upon request.
Looking for a custom microfluidic component or precision micro-machining solution for your next setup?
