Yb:YAG Laser Crystal | 1030 nm High-Power Gain Medium
Yb:YAG Laser Crystal | 1030 nm High-Power Gain Medium
Couldn't load pickup availability
Yb:YAG (Ytterbium-doped Yttrium Aluminum Garnet) laser crystals are widely used in modern high-power and high-efficiency solid-state laser systems.
With a simple energy-level structure and low quantum defect, Yb:YAG offers excellent thermal performance and high slope efficiency, making it ideal for diode-pumped lasers.
Our Yb:YAG crystals are laser-grade, featuring high optical uniformity, low absorption loss, and precision optical polishing suitable for CW, pulsed, and ultrafast laser designs.
Key Features
- High efficiency at 1030 nm
- Low quantum defect → reduced thermal load
- Excellent thermal conductivity and mechanical strength
- High damage threshold
- Laser-grade optical polishing
- Custom sizes, dopant levels, and coatings available
Typical Specifications
- Material: Yb³⁺:Y₃Al₅O₁₂ (Yb:YAG)
- Dopant concentration: 3–10 at.% (custom available)
- Laser wavelength: 1030 nm
- Pump wavelength: ~940 nm
- Crystal orientation: ⟨111⟩ or ⟨100⟩
- Surface quality: 10/5 or 20/10 scratch-dig
- Flatness: λ/10 – λ/4
- Parallelism: < 10 arcsec
- Polishing: Double-side optical polish
- Coatings: AR @ 940 nm / 1030 nm (optional)
Applications
- High-power DPSS lasers
- Thin-disk laser systems
- CW and pulsed solid-state lasers
- Ultrafast and femtosecond lasers
- Industrial material processing
- Scientific and academic research
Customization & Fabrication
We support:
- Custom dimensions and geometries
- Dopant concentration tuning
- AR / HR optical coatings
- Precision cutting & polishing
- OEM and bulk orders
University & Research Support
- Academic discounts available
- Tax-exempt orders supported
- Technical consultation included
Yb:YAG Laser Crystal – FAQ
What wavelength does Yb:YAG operate at?
Yb:YAG lasers typically operate at 1030 nm and are pumped around 940 nm.
Why choose Yb:YAG instead of Nd:YAG?
Yb:YAG offers higher efficiency and lower thermal load due to its low quantum defect, making it ideal for high-power and ultrafast lasers.
What dopant concentrations are available?
Standard Yb:YAG concentrations range from 3–10 at.%. Custom concentrations are available.
Do you offer custom sizes or shapes?
Yes. Rods, slabs, discs, thin-disk formats, and custom geometries are supported.
Are AR coatings available?
Yes. AR coatings at 940 nm (pump) and 1030 nm (laser) are available, including dual-band designs.
What is the typical lead time?
In-stock items ship in 1–2 business days. Custom orders typically require 2–3 weeks.
